Boshun Belting is the leading manufacturer of conveyor belt for stone & ceramics industry. As our main products, our belts have characteristics of cut-resistant, abrasion-resistant, flatness and high breaking strength, etc. We supply belts to many ceramics and marble equipment manufacturers all over the world, promoting production quality and collocation in deep cooperation.
| Type | Thickness (mm) |
Ply | Effective pull at 1% elongation (N/mm) |
Min diameter (mm) |
Temperature range (℃) |
|
| 70P39-28/15 | 7.0 | 3 | 50 | 350 | -15/80 | 70P39-28/15 3 White Smooth 7.0mm 2.0/1.0mm 8.4Kg/㎡ 50N/mm 350mm -15/80℃ https://www.boshunbelting.com #ffffff Material conveying |
| 70P39-76/4 | 7.0 | 3 | 50 | 350 | -15/80 | 70P39-76/4 3 Petrol Round nipple 7.0mm 2.0mm 8.0Kg/㎡ 50N/mm 350mm -15/80℃ https://www.boshunbelting.com #215867 Stone & Ceramics |
| 70P39-76/25 | 7.0 | 3 | 50 | 350 | -15/80 | 70P39-76/25 3 Petrol Low grip 7.0mm 2.0mm 8.2Kg/㎡ 50N/mm 350mm -15/80℃ https://www.boshunbelting.com/public/uploads/20181227/6168a544609d4e492c032f553b0f8b72.jpg #215867 Stone & Ceramics |
| 90P32-36/13 | 9.0 | 3 | 13 | 120 | -15/80 | 90P32-36/13 3 Black Square 9.0mm 6.0mm 8.0Kg/㎡ 13N/mm 120mm -15/80℃ https://www.boshunbelting.com/public/uploads/20181218/c57184ed99593117e8b2d4a4ffac4cd5.jpg #000000 Wood |
| 90P39-78/15 | 9.0 | 3 | 70 | 450 | -10/80 | 90P39-78/15 3 Petrol Small golf 9.0mm 2.0/2.0mm 10.8Kg/㎡ 70N/mm 450mm -10/80℃ https://www.boshunbelting.com #215867 |
| 90P49-76 | 9.0 | 4 | 70 | 450 | -15/80 | 90P49-76 4 Petrol Smooth 9.0mm 2.0mm 10.8Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com #215867 |
| 90P49-76/4 | 9.0 | 4 | 70 | 450 | -15/80 | 90P49-76/4 4 Petrol Round nipple 9.0mm 1.9mm 9.7Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com #215867 |
| 90P49-76/25 | 9.0 | 4 | 50 | 450 | -15/80 | 90P49-76/25 4 Petrol Low grip 9.0mm 2.5mm 10.6Kg/㎡ 50N/mm 450mm -15/80℃ https://www.boshunbelting.com #215867 |
| 90P49-86/49 | 9.0 | 4 | 70 | 400 | -10/80 | 90P49-86/49 4 Blue Y pattern 9.0mm 2.5mm 10.8Kg/㎡ 70N/mm 400mm -10/80℃ https://www.boshunbelting.com #0070c0 |
| 110P39-76/23 | 11.0 | 3 | 50 | 350 | -15/80 | 110P39-76/23 3 Petrol Tooth (one direction) 11.0mm 6.8mm 8.4Kg/㎡ 50N/mm 350mm -15/80℃ https://www.boshunbelting.com #215867 |
| 110P39-76/34 | 11.0 | 3 | 50 | 350 | -15/80 | 110P39-76/34 3 Petrol Tooth (two-direction) 11.0mm 6.8mm 8.4Kg/㎡ 50N/mm 350mm -15/80℃ https://www.boshunbelting.com #215867 |
| 115P39-76/23 | 11.5 | 3 | 50 | 350 | -20/60 | 115P39-76/23 3 Petrol Tooth (one direction) 11.5mm 7.3mm 8.5Kg/㎡ 50N/mm 350mm -20/60℃ https://www.boshunbelting.com #215867 |
| 120P42-74/0H(1)RED | 12.0 | 4 | 25 | 200 | -10/90 | 120P42-74/0H(1)RED 4 Red Matt 12.0mm 6.0mm 14.4Kg/㎡ 25N/mm 200mm -10/90℃ https://www.boshunbelting.com #ff0000 |
| 125P49-76/23 | 12.5 | 4 | 70 | 450 | -20/60 | 125P49-76/23 4 Petrol Tooth (one direction) 12.5mm 7.3mm 10.1Kg/㎡ 70N/mm 450mm -20/60℃ https://www.boshunbelting.com #215867 |
| 125P49-76/34 | 12.5 | 4 | 70 | 450 | -15/80 | 125P49-76/34 4 Petrol Tooth (two-direction) 12.5mm 7.3mm 10.1Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com #215867 |
| 130P49-76/23 | 13.0 | 4 | 70 | 450 | -15/80 | 130P49-76/23 4 Petrol Tooth (one direction) 13.0mm 6.0mm 10.8Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com #215867 |
| 130P49-76/34 | 13.0 | 4 | 70 | 450 | -15/80 | 130P49-76/34 4 Petrol Tooth (two-direction) 13.0mm 6.5mm 11.1Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com/public/uploads/20190320/4ee789a75129577591eabc16ff2e2b0f.jpg #215867 Stone & Ceramics |
| 40P33-27G | 4.0 | 3 | 10 | 140 | -15/80 | 40P33-27G 3 White Fabric 4.0mm 1.0mm 4.8Kg/㎡ 10N/mm 140mm -15/80℃ https://www.boshunbelting.com/public/uploads/20181214/6d9e8120e669b21631781f5ab9099f55.jpg #ffffff Automotive & Tyre |
| 130P49-86/34 | 13.0 | 4 | 70 | 450 | -15/80 | 130P49-86/34 4 Blue Tooth (two-direction) 13.0mm 6.5mm 11.1Kg/㎡ 70N/mm 450mm -15/80℃ https://www.boshunbelting.com/public/uploads/20181219/470d0a29cf34bf0cf63a2501183cec63.jpg #0070c0 Stone & Ceramics |
| 50P32-76/4 | 5.0 | 3 | 18 | 150 | -15/80 | 50P32-76/4 3 Petrol Round nipple 5.0mm 2.0mm 5.6Kg/㎡ 18N/mm 150mm -15/80℃ https://www.boshunbelting.com/public/uploads/20190315/cf1d36011324b4955702a0edfeb19a9e.jpg #215867 Stone & Ceramics |
